15kwh High Voltage Lithium Battery Powerbank
The easy-maintainable 15kwh High Voltage Lithium Battery Powerbank is a high-voltage lithium iron phosphate (LiFePO4) battery designed for use in solar energy systems, backup power, and other off-grid applications.
Send Inquiry
Product Description
High-voltage Battery
TG-HB-10000W | 15000W | 20000W | 25000W
> With a scalable modular design , the capacity range can be expanded from 10.24kWh to 25.6kWh.
> The installation and maintenance is easier and faster with free of cables between modules.
> Long life technology ensures more than 6000 cycles with 90% DOD.
The newest 15kwh High Voltage Lithium Battery Powerbank is a high-voltage lithium iron phosphate (LiFePO4) battery designed for use in solar energy systems, backup power, and other off-grid applications. It has a capacity of 15 kilowatt-hours (kWh), which means it can store up to 15 kilowatt-hours of energy.
This battery is stackable, which means that multiple batteries can be connected together in parallel or series to increase the overall capacity of the energy storage system. Each battery in the stack features a high-quality battery management system (BMS) that protects against overcharging, over-discharging, short circuits, and other issues that can reduce the lifespan of lithium-ion batteries.
The 15kwh High Voltage Lithium Battery Powerbank is compatible with a range of inverters, charge controllers, and other components commonly used in solar energy systems.
This battery is designed for easy installation and maintenance. It is also highly efficient, which means that it can store and release energy with minimal losses. It has a long cycle life, meaning that it will last for many years before needing to be replaced.
Overall, the 15kwh High Voltage Lithium Battery Powerbank is a reliable and high-performance solution for energy storage applications that require high voltage levels and scalability. It can help to reduce energy costs and improve the efficiency of a solar energy system or other off-grid power system.
Scalable
Use of Series connection from 2 to 5 modules
Safe
Multiple protection LiFePO4 material, safe and long life.
Convenient
Stackable & compact design,ease of installation
Compatible
Compatible with multiple inverters Multiple communication interfaces RS232, RS485, CAN
Compliant
Ip65 Protection, indoor or outdoor application
Technical Parameters
| PERFORMANCE SPECIFICATIONS | ||||
| Model | TG-HB-10000W | TG-HB-15000W | TG-HB-20000W | TG-HB-25000W |
| Nominal Voltage | 204.8V(64series) | 307.2V(96series) | 409.6V(128series) | 512V(160series) |
| Cell model / Configuration | 3.2V 50Ah(ANC)/32S1P | |||
| Capacity(Ah) | 50AH | |||
| Rated Energy(KWH) | 5.12KWH | |||
| Usable Energy (KWH) | 4.6KWH | |||
| Max. Charge / Discharge Current(A) | 25A /50A | |||
| Voltage Range(Vdc) | 180-228V | 270-340V | 350-450V | 440-560V |
| Scalability | Up to 1 parallel | |||
| Communieation | RS232-PC,RS485-Inverter,Canbus-Inverter | |||
| Cycle Life | ≥6000cycles@25℃，90% DOD，60%EOL | |||
| Design Life | ≥15 Years(25℃） | |||
| MECHANICAL SPECIFICATIONS | ||||
| Weight(Approx)(KG) | Approx:130kg | Approx:180kg | Approx:230kg | Approx:280kg |
| Dimension (W/D/H)(mm) | 630*185*950 | 630*185*1290 | 630*185*1640 | 630*185*1980 |
| Installation Mode | Stack | |||
| IP Grade | Ip65 | |||
| SECURITY AND CERTIFICATION | ||||
| Safety(Pack) | UN38.3,MSDS,IEC62619(CB),CE-EMC,UL1973 | |||
| Safety(Cell) | UN38.3,MSDS,IEC62619,CE,UL1973,UL2054 | |||
| Protection | BMS, Breaker | |||
| ENVIRONMENTAL SPECIFICATIONS | ||||
| Operating Temperature(℃） | Charge:-10℃~50℃；Discharge：-20℃-50℃ | |||
| Altitude (m) | ≤2000 | |||
| Humidity | ≤95%(Non-condensing） | |||
