15kwh Lithium Battery DIY Pack
The fashion 15kWh lithium battery DIY pack is a customizable energy storage solution for solar power systems.
Send Inquiry
Product Description
15kwh Lithium Battery DIY Pack
The newest 15kwh Lithium Battery DIY Pack can be charged during the day and provide energy during the night hours when the solar panels are not working. They have a larger capacity and can store more energy than other types of batteries. You will be able to use your home appliances during the night instead of having to rely on diesel-powered generators or other types of equipment that consume too much energy. The type of lithium-ion battery used in 5kwh Lithium Battery Stackable is lithium iron phosphate (LiFePO4), which is known for its high energy density, long cycle life, and high safety standards.
One Pack
We offer all necessary components in one package,you don’t need to buy anything else by yourself.
Easy Work
The 15kwh Lithium Battery DIY Pack is easy to assemble,you can just follow our instruction video to do it by yourself.
Elegant look
The 15kwh Lithium Battery DIY Pack is just as elegant look as your inverter, your home appliances,your neighbours will never find out that you did it yourself.
The battery cells used in the DIY pack are lithium iron phosphate (LiFePO4) that have been arranged in a series and parallel configuration to achieve the desired voltage and capacity. The battery cells are connected to a battery management system, which monitors and controls the charging and discharging of the battery to ensure proper operation and to maximize the efficiency of the system.
When you receive the 15kwh Lithium Battery DIY Pack, please check the parts list first：
15kwh Battery Parts List:
| No. | Item Name | Qty | Unit | Check | No. | Item Name | Qty | Unit | Check |
| 1 | Blade cell 3.2v184ah (including cell holders) | 16 | pcs | 11 | Bus bar #5 | 12 | pcs | ||
| 2 | Terminal port(+/-) | 4 | pcs | 12 | Bus bar #6 | 2 | pcs | ||
| 3 | Power switch | 1 | pcs | 13 | M3*8 screws kit | 1 | pcs | ||
| 4 |
BMS 16s100A With Customized cell wire |
1 | set | 14 | M4*8 countersunk screw | 9 | pcs | ||
| 5 | Insulated wire sleeve | 1 | pcs | 15 | M4*10 screws kit | 20 | pcs | ||
| 6 |
Battery case (including mounting bracket) |
1 | pcs | 16 | M5*10 screws kit | 28 | pcs | ||
| 7 | Bus bar#1 | 1 | pcs | 17 | M6*12 screws kit | 4 | pcs | ||
| 8 | Bus bar #2 | 1 | pcs | 18 | M6 nut | 32 | pcs | ||
| 9 | Bus bar #3 | 1 | pcs | 19 | ExpansionM8*100 | 2 | pcs | ||
| 10 | Bus bar #4 | 1 | pcs | 20 | Battery cable 4AWG | 3 | meter |
Then please follow the steps below or the installation video to assemble it. If you need anything, please feel free to contact us.
| Model | 9Kwh | 14Kwh | 15Kwh |
| Battery Type | LiFePO4 Blade Cell | LiFePO4 Cell | LiFePO4 Cell |
| Battery Grade | Brand New Grade A Cell | ||
| Brand | SVOLT | HITHIUM/EVE/REPT*1 | CATL/EVE/BYD/REPT*1 |
| Nominal Voltage | 51.2V | ||
| Rated Capacity | 184Ah | 280Ah | 304/31OAh |
| Nominal Current | 1OOA/15OA/2OOA *2 | ||
| Nominal Energy | 9.42Kwh | 14.336Kwh | 15.56Kwh/15.87Kwh |
| Operating Temperature*3 |
0℃~ 55℃(Charging)
20℃~ 60℃(Discharging)
|
||
| General | |||
| Installation | Wall-mounted | Floor-mounted | Floor-mounted |
| Battery Box | Steel*4 | ||
| Dimension(L/W/D) | 850*500*150mm | 880*520*170mm | 880,520*170mm |
| Weight | 76kg | 113kg | 113kg |
| Scalability | Up to 16 units | ||
| Protection Class | IP31 | ||
| DOD | 90% | ||
| Communication | CAN2.0/RS485 | ||
| Warranty | 5 Year product warranty | ||
| Guaranteed Cycles | >6000*5 | ||
*1.Battery Cell is optional.
*2.BMS current is optional.
*3.When the temperature is below 0℃ or above 45℃, the performance will be limited.
*4.Customized logo & DIY UV printing are available.
*5.Test conditions:0.2C charging/discharging,@25℃,80%DOD.
Situation
Due to unstable power sources and unreliable grid connections, there are frequent power outages in rural areas. Not only that, but rising electricity prices are becoming more and more worrying.
Application
Sunlink’s DIY Lithium Battery Pack can realize off-grid and grid-connected power generation functions and realize two-way flow control of electric energy, which is suitable for small-capacity home power backup scenarios.
Solution
By installing Sunlink’s DIY Lithium Battery Pack, people’s rural electricity problem is solved, not only at low cost but also in line with their environmental protection concept.
